Variable cross-section fuse element made from pure metal sealed in cartridge made from high temperature resistant epoxy glass. Fuse tube filled with chemically treated high-purity quartz sand as arc-extinguishing medium. Dot-welding of fuse element ends to the knife contacts ensures reliable electric connection.



Protection against overload and short-circuit in electric lines and equipments (type gG), also available for protection of
motors (type aM).Rated voltage up to 600V; Rated current up to 630A; Working frequency 50Hz AC; Rated breaking capacity up to 100KA. Compliant with GB13539 and IEC269.
